Description

Make sure this fits by entering your model number.
【Please Download the User Manual and Warranty Documents from the "Warranty Description" item below.】The VLC2.0 controller can perform a variety of control functions by adjusting the timer, each time relay can run individually, there also can run in turn, dual time relay can be controlled by detect dual channel voltage.
Such as control two loads simultaneously or alternately ON/OFF, single-phase motor positive and reversion according to the timing, or DC motor positive and reversion, or dual solenoid valve timing work in rotation (controlled pneumatic) or dual alternating bright lights etc.
Digital LED displays, set by three keys, simple, powerful, with reset settings function. High-performance microcontrollers, industrial-grade reliability, high process stability, low power, digital displays can be automatically off , the minimum operating current at 7mA/12V, with reverse power protection , surge current shock protection .
Each group of relay contacts to a common and normally open, normally close, two sets of conversion; Dual time relay, timer range: 0.1 seconds ~ 9999 minutes adjustable, close/ open cycles is adjustable from 0 to 999 ( “0” means infinite loops ) , timer relays can be set to close first or open first;
Dual relay can take turns running, after the end of timer relay A then timer relay B began to run, turn the cycle ,the timer can be triggered by high level or switch to start and forced stop (P-3 mode ) ; Dual relay run individually, can be high or switch to trigger the start (P-4 mode) ; Dual voltage detection control relays, the detection voltage range: DC 0 ~ 99.9V; All parameter settings can be saved, the next time modes and parameters continue to the last running.
User Manual www.desertcart.com/clouddrive/share/2No29viguVoCm9KFEMLpoLcJv5sCa3B9YrtjG9Ozzxl

NOYITO 2-Channel Programmable Time Relay Module Dual Relays Triggered in Turn or Individually 2-Channel 0-99.9V Voltage Detection Control Board Cyclic Timing On Off (12V)

Reviews

J**A

Does it’s job

It’s a pretty good unit. Very functional. The instructions suck. It took a little trial and error to get it to work for me. Once I figured it out it does exactly what I wanted. Would be a 5 star if the instructions were any good.

30.07.2020

P**L

HORROR - MISSERY - GARBAGE - A RIP OFF

A VERY UNSTABLE DESIGN AND FORGET TECH SUPPORT - EVEN THE DIRECTIONS MAKE NO SENSE AT ALL

21.07.2022

C**R

Works great...what box for it

It works great, easy to setup and useWhat box or case can we buy for it??

18.04.2020
